TrueOak Tilt & Turn

Engineered for Every Moment

Two modes of operation, one elegant window.

The TrueOak tilt and turn Windows offer a sophisticated blend of versatility and elegance. These windows are engineered to tilt for secure ventilation or swing open for full access, combining modern functionality with a sleek, space-saving design suitable for any residence.

Features

  • Any RAL Classic Powder Coat Color, any Sherwin Williams color, and select stain colors

  • Availability To Match Colors to Other Materials

  • German Components
  • German Handles
  • Warm Edge Spacers
  • Argon Gas Filled Tempered Glass (Dual or Triple Glazed)
  • Low-E Technology

  • 20 Year Transferable Warranty

  • 5 Layer Zero Damage Packaging

  • Hidden Integrated Drainage

  • Available For SDL’s or Grids Between The Glass
  • Available as single color or 2-tone (Exterior/Interior)

Performance

Model TrueOak e80s Tilt & Turn

Glazing Options: Double-pane Triple-pane
Energy Ratings: U-Value SHGC U-Value SHGC
Picture Window 0.30 0.25 0.24 0.23
Tilt & Turn Window 0.31 0.22 0.27 0.21

CW-PG50-1250x1850mm (49.21×72.83 in) -Type DAW
DP: +2400/-2400 Pa (+50.13/-50.13 psf)
Water Test Pressure: 440Pa (9.19 psf)
Canadian Air Infiltration/Exfiltration: A3
Conforms to AAMA / WDMA / CSA 101/I.S.2/ A440-11 & CSA A440S1-17

Frame: Aluminum w/ Thermal Break, 6060-T66 Profile,

≥2.0mm Thickness, 3-1/8″ Jamb Depth

Finish: Powder Coating-20 Years Warranty

Sherwin Williams Paint

Select Stains

Glass: ◆Tempered Safety Glass

              ◆Ultra Clear Glass

              ◆Double-pane (1/4″ TG+1/2″ Air Space+1/4″ TG), Triple-pane Optional

              ◆Argon Fill

              ◆Double-silver LowE Coating

              ◆Warm-edge Spacer

Hardware: Concealed or exposed Hinges, Multi-point,Locking System. German Hoppe handles

Weather Seals: Three layers of EPDM Weather Stripping

Screen Options: Fixed Removable Screen, Retractable Screen

Installation: New or replacement available

Functionality: Picture Window, Tilt & Turn Window, Tilt-in Window

Grids: No Grid. GBG, SDL or Custom Grilles Optional
